Technical Parameter：

Input Voltage Range: DC9V-16V

Typical Operating Voltage: DC12.8V

Typical Input Current: 3.2A, Condition: DC 12.8V Input

Max. Inrush Current: 15A

Output Power: 33W±2W (Constant Power)

Output voltage: AC85V±15V (Square Pulse, RMS70V-100V)

Output Frequency: 260Hz～280Hz

Efficiency: ≥83%

Ignition pulse: Typical peak Voltage 23kV

     Typical duration：1s

Cooling method: Natural cooling

Input Protections: Under voltage protection at 6V±1V

     Over voltage protection at 34.5V±1V

     Input connection-reverse protection

Output Protections: Short circuit protection between two outputs

      Open circuit protection between two outputs

Operating temperature: -30℃～＋ 85℃

Storage temperature: -40℃～＋105℃

Warning Notice

1 Do not attempt to handle or operate an electronic power supply (EPS) and ignitor before completely reading and understanding this notice. Contact EPE if you are uncertain of characteristics of these devices.

2 The ignitor produces starting voltages of up to 23kV and electromagnetic radiation interference, which are hazardous to personnel and sensitive instrumentation. Do not touch any conductive parts during operation.

3 Both electronic lamp ballast and ingnitor must never be installed or operated in an explosive or volatile atmosphere. Never use the ballast or ignitor near flammable gases or liquids. See that there will be no moisture, dust or similar which could lead to short circuits or fire.

4 Before using the ballast or ignitor in any kind of outdoor application you have to take additional measures and observe special requirements. If you are uncertain, contact EPE.

5 No potential isolation is provided between line input and output. Accidentally grounding of an output terminal by direct contact or arcing to GND can damage the unit (no warranty replacement).

6 All installation and repair work on this unit is only permitted by qualified personnel.

7 Please provide sufficient cooling condition for EPS and ignitor.

8 EPE does not assume liability for disregarding of this notice, incorrect use of the EPS and ignitor or disregarding of any legal requirements.  This product is subject to technical changes without prior notice.
